Solar LED Street Light

Short Description:

All In Two Solar LED Sreet Light 15W.20W.30W.40W.50W.60W Application: * Street lighting * Car Park & Perimiter Lighting * Villa path Lighting * Express way lighting * Construction Sites * Rural & Remote Area Lighting * Outdoor Shopping Lighting Model Option: 15W.20W,30W.40W.50W.60W ALL IN TWO SERIES SOLAR LED STREET LIGHT With Separate Solar PV Key Advantages: -PROGRAMMABLE Smart solar controller built-in power brightness and lighting time are adjustable via remote controller. -...


Product Detail

Product Tags

All In Two Solar LED Sreet Light 15W.20W.30W.40W.50W.60W
Application:
* Street lighting
* Car Park & Perimiter Lighting
* Villa path Lighting
* Express way lighting
* Construction Sites
* Rural & Remote Area Lighting
* Outdoor Shopping Lighting
Model Option: 15W.20W,30W.40W.50W.60W
ALL IN TWO SERIES SOLAR LED STREET LIGHT With Separate Solar PV
Key Advantages:
-PROGRAMMABLE
Smart solar controller built-in power brightness and lighting time are adjustable via
remote controller.
-MICROWAVE SENSOR
More area can be covered than PIR sensor; longer distance and wider sensitive angle, more
stable than PIR.
-EXTERNAL SOLAR PANEL
Solar panel separated from light allows to increase power to meet the solar radiations in
different latitude and longitude. Max 200W solar panel is allowed for 50W LED with 6200lm output.
-CONNECTION
MC4 male & female plugs directly to 18V solar panel. quick and easy for connection.
2.5mm² power cord for less voltage drop.
-COMPACT SYSTEM
Battery and solar controller, sensor are built-ins ide of light, only need to be connected to 18V system, NO more other operation, easy, simple and quick installation.
slsl03slsl01slsl02

Model Selection

Model No.

SN-U15W

SN-U20W

SN-U30W

SN-U40W

SN-U50W

SN-U60W

Fixture IP

                                        IP67



LED Power Max

15W

20W

30W

40W

50W

60W

Luminous Flux

>2,200lm

>2,800lm

>3,600lm

>5,200lm

>6,200lm

>7,200lm

Beam angle

140*70 Degrees



Color Temp.

2700K ~ 6500K Optional

CRI

>83

LED Brand

Philips SMD3030

LED Qty

48Pcs

72Pcs

90Pcs

Battery Capacity

195WH 12V

293WH 12V

391WH 12V

488WH 12V

548WH 12V

635WH 12V

Charge Time

6 Hours



Max Discharge Time

>48 Hours



Controller Type

 PWM type with sensor

             MPPT type with sensor

Solar Panel(Poly)

40W 18V

50W 18V

60W 18V

80W 18V

100W 18V

120W 18V

V.mp. of PV

18V

18V

18V

18V

18V

18V

I.mp. of PV

2.22A

2.78A

3.33A

4.45A

5.56A

6.67A

PV Size(mm)

670*390*25

620*535*30

670*560*25

760*670*30

1000*680*30

1050*670*30

Flexible PV Option

Thin Film 40W

Semi Flex 40W

Thin Film 52W

Semi Flex 50W

Thin Film 65W

Semi Flex 60W

Thin Film 79W

Semi Flex 80W

Thin Film 105W

Semi Flex 100W

Thin Film 144W

Semi Flex 120W

Working Temp.

-20 °C ~ +65 °C

Lighting Modes

                     Remote Control Unit

Pole Height

3~4 M

3~5M

3~6M

4~6M

5~8M

6~12M

Packing

2PCS/CTN, CTN SIZE: 65*32*36CM, QTY/20GP : 720PCS, QTY/40HQ : 1500PCS

48PCS LED-3-1
