100W I-CLOUD All In One Solar Light
100W I-CLOUD ALL IN ONE SOLAR LIGHT(SNW-2100)
Application: For Carport, Stadium, Square and Street Lighting.
Model No.: SN-W2100
100W LED Integrated with 130W PV and 77AH Battery
APP REMOTE CONTROL
• Modify specification remotely
• Sub-street light networking
• Available to send voice notification remotely
• Music play remotely
• Video real-time monitoring
• Remote alarm function
• Key alarm on the pole
• Available to check video history record remotely
• Automatically error warning remotely
• GPRS positioning
General Specification
|
LED power |
100W |
|
Solar panel |
130W, Cell brand: Solarworld |
|
Lithium Battery |
77AH Lithium |
|
Lumen |
10000~11000lm |
|
Mounting height |
9-11m |
|
Mounting distance |
35~40m for one-way road,60-70m for two-way road, intercross distance. |
|
Working Method |
Timer control, APP |
|
Waterproof degree |
IP65 |
|
LED Beads Qty |
102; LED Brand: Bridgelux 45 |
|
CCT |
3000~6000K |
|
Working Temp. |
-30~+60C |
|
Working Humidity |
15~90%RH |
Installation
Packing Detail
|
Product size/Weight |
1570*460*45mm/22KG |
|
Pack size/ Weight |
1650*530*200mm /26KG |
