G02 Elite Split Solar Light 30W.40W.50W.60W
G02 Elite Split Solar Light 30W.40W.50W.60W
Application: For Garden Lighting, Landscape Lighting, Residential Lighting,
Model No.: G02-30W, G02-40W, G02-50W, G02-60W
Model: G02-30W
SPLIT TYPE, 30W LED Integrated with 60W PV and 244.2WH Battery
General Specification
|
LED power |
30W |
|
Solar panel |
60W, 18V Cell brand: Solarworld |
|
Lithium Battery |
11.1V/244.2WH |
|
Lumen |
3900~4500lm |
|
Mounting height |
6-7m |
|
Mounting distance |
20m for one-way road,40m for two-way road |
|
Working Method |
Timer control, Motion sensor，APP |
|
First 6 hrs |
100% power lighting when people pass by,lasting 20-30 seconds, and 50% when no people |
|
Last 6 hrs |
60% power lighting when people pass by,lasting 20-30 seconds, and 30% when no people. |
|
Light source |
3535LED/42PCS |
|
LED Brand |
USA Bridgelux 45mil |
|
CCT |
3000~6500K |
|
Working Temp. |
-30~+60C |
Model: G02-40W
SPLIT TYPE, 40W LED Integrated with 60W PV and 293WH Battery
General Specification
|
LED power |
40W |
|
Solar panel |
60W, 18V Cell brand: Solarworld |
|
Lithium Battery |
11.1V/290WH |
|
Lumen |
5000~6000lm |
|
Mounting height |
6-7m |
|
Mounting distance |
30m for one-way road,45m for two-way road |
|
Working Method |
Timer control, Motion sensor，APP |
|
First 6 hrs |
100% power lighting when people pass by,lasting 20-30 seconds, and 50% when no people |
|
Last 6 hrs |
60% power lighting when people pass by,lasting 20-30 seconds, and 30% when no people. |
|
Light source |
3535LED/42PCS |
|
LED Brand |
USA Bridgelux 45mil |
|
CCT |
3000~6500K |
|
Working Temp. |
-30~+60C |
Physical map
Model: G02-50W
SPLIT TYPE, 50W LED Integrated with 80W PV and 341.9WH Battery
General Specification
|
LED power |
50W |
|
Solar panel |
80W, 18V Cell brand: Solarworld |
|
Lithium Battery |
11.1V/341.9WH |
|
Lumen |
6500~7500lm |
|
Mounting height |
8-9m |
|
Mounting distance |
40m for one-way road,60m for two-way road |
|
Working Method |
Timer control, Motion sensor，APP |
|
First 6 hrs |
100% power lighting when people pass by,lasting 20-30 seconds, and 50% when no people |
|
Last 6 hrs |
60% power lighting when people pass by,lasting 20-30 seconds, and 30% when no people. |
|
Light source |
3535LED/60PCS |
|
LED Brand |
USA Bridgelux 45mil |
|
CCT |
3000~6500K |
|
Working Temp. |
-30~+60C |
Model: G02-60W
SPLIT TYPE, 60W LED Integrated with 80W PV and 390.7WH Battery
|
LED power |
60W |
|
Solar panel |
80W, 18V Cell brand: Solarworld |
|
Lithium Battery |
11.1V/390.7WH |
|
Lumen |
7800~9000lm |
|
Mounting height |
8-10m |
|
Mounting distance |
45m for one-way road,65m for two-way road |
|
Working Method |
Timer control, Motion sensor，APP |
|
First 6 hrs |
100% power lighting when people pass by,lasting 20-30 seconds, and 50% when no people |
|
Last 6 hrs |
60% power lighting when people pass by,lasting 20-30 seconds, and 30% when no people. |
|
Light source |
3535LED/60PCS |
|
LED Brand |
USA Bridgelux 45mil |
|
CCT |
3000~6500K |
|
Working Temp. |
-30~+60C |
